WW-P03 · Forged passenger and touring wheels
Ten-Spoke Forged Passenger Wheel - 1010
Passenger-car aftermarket with square or staggered sets; approve axle-specific dimensions.
| Design model | 1010 |
|---|---|
| Size | 19 x 8.5 in (482.6 x 215.9 mm) |
| PCD range | 3.937 to 4.724 in (100 to 120 mm) |
| ET range** | 0.984 to 1.772 in (25 to 45 mm) |
*U.S. procurement target, not approved fitment. **ET shown for first listed size. Confirm alloy, process, load and tests.
Construction & Material
Alloy wheel in the forged-wheel program. Confirm alloy, heat treatment and complete-wheel construction by model.
Options
Proposed 5 x 4.500 in (5 x 114.3 mm); lock each width and ET separately.
Size options
19 x 8.5 in (482.6 x 215.9 mm); 19 x 9.5 in (482.6 x 241.3 mm); 20 x 8.5 in (508 x 215.9 mm); 20 x 9.5 in (508 x 241.3 mm)
Procurement Value
An identified ten-spoke design supports a repeatable fitment and finish program.
Mounting & Selection
Vehicle/year/trim, brake package, diameter/width, lug count/PCD, center bore, offset, load, TPMS and finish.
Standards & Qualification
FMVSS 110/120 applicability; SAE J2530 aftermarket test program. Fitment and test evidence are required for the supplied configuration.
Packing & Delivery
Actual packed dimensions, gross mass and stack limit to be confirmed. Protect rim edges and finished surfaces. Matched multi-piece components must be secured and identified together.
Model Approval
Confirm the quoted model, production drawing, load and fitment evidence before ordering. Reference specifications are not a supply guarantee.
